VELP BOD EVO SENSOR SYSTEM 6 WITH WIRELESS DATABOX
|
Remote Operation
- Unique and revolutionary wireless sensor transmits data
- Wireless DataBox™ records transmitted data
- Dedicated BODSoft™ software processes the data
- Up to 80 sensors can be monitored simultaneously
Precise Control
- Measurement on scales of 90, 250, 600 and 999 ppm BOD
- Higher values can be measured by diluting the sample
- Models with stirring stations offer VELP stirring quality
Extremely Practical
- Fits directly on the bottle containing the sample
- Customisable intervals, automatic storage of the data
- Enables analysis to continue over the weekend
- Results directly readable at any time, even after five days
- Direct readout in mg/l (ppm) and graph creation on PC
- Compact stirring stations
Priority to Safety
- IP 54 protection against particle and liquid ingress
- Class 3 IEC 1010 conformity
Complete Package
- BOD EVO Sensor System 6, a complete package for 6 tests
- 6-position stirring station, 6 BOD EVO Sensors, dark glass bottles, alkali holders & stirring bars
|
|
GENERAL FEATURES
| Construction material: | Technopolymer |
| Power: | 2 W |
| Power supply: | 115 V or 230 V / 50-60 Hz |
| Dimensions (WxHxD): | 270x300x185 mm (10.6x11.8x7.3 in) |
| Weight: | 2.3 Kg (5.1 lb) |
|
|
PERFORMANCE
| Reading value | mg/l (ppm) directly on PC (or on the display) |
| Measurement by electronic pressure probe |
| Bottle total capacity: | 500 ml |
| Data storage for BOD5: | Every 30 min / 1 / 2 / 4 / 6 / 8 / 12 / 24 hours |
| Data storage for longer test: | Every 2 / 4 / 6 / 8 / 12 / 24 hours |
| BOD values: | Automatic data calculation and management from BODSoft™ |
| BODlast determination: | Possible |
| Scales: | 90, 250, 600, 999 ppm BOD. Higher values after dilution |
| Display: | Digits 3 LED |
| Safety class: | 3 IEC 1010 |
| Electronic protection degree CEI EN 60529: | IP 54 |
|
