IP0891 BT102S Microflow Variable-Speed Peristaltic Pump
|
BT102S Suitable Pump Heads and Tubings, Flow Parameters
| Pump Head for Drive Type: BT102S | Channels | Tube Sizing | Single Channel Flow Rate(mL/min) |
| DG | 1.2 | Wall:0.8~1, ID:≤3.17 | 0.0001-49 |
| DT10-18 | 1 | Wall:0.8~1, ID:≤3.17 | 0.0002-82 |
| DT10-28 | 2 | Wall:0.8~1, ID:≤3.17 | 0.0002-82 |
| YZ15 | 1 | 13# 14# 16# 19# 25# 17#18# | 0.006-380 |
| YZ25 | 1 | 15# 24# | 0.16-280 |
| YT15 | 1 | 13# 14# 16# 19# 25# 17#18# | 0.006-380 |
IG0036 SPECIFICATIONS
| Flow range: | 0.0001-480 mL/min |
| Speed range: | 0.1-100 rpm |
| Speed resolution: | 0.1 rpm |
| Speed accuracy: | 0.5% |
| IP grade: | IP31 |
| External communication interface: | RS485 MODBUS |
| External logic level control signal: | 5V, 12V (standard), 24V (optional). External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional) |
| Power supply: | AC 100-240V 50Hz/60Hz |
| Power consumption: | <30 watts |
| Working environment: | 0 -40℃ Relative humidity <80% |
| Weight: | 2.7kg |
| IP Standard: | IP31 |
| Dimension: | (L x W x H): 224 x 127 x 128 mm |
|
|
