DISTILLATION UNIT, AUTOMATIC KJELDAHL ANALYSER, 6" COLOUR TOUCH SCREEN, INTEGRATED COLORIMETRIC TITRATOR, 230V 50-60Hz, UDK159
|
Automated Operation
- Programmable boric acid, water, sodium hydroxide addition
- Not necessary to set distillation time when titrating
- Incorporates an AOAC recommended colorimetric titrator
- Selectable steam generation output level 10% – 100%
- Auto removal of residues from titrator & sample tube
High Tech
- 6 inch colour touch screen
- Library of 55 programs (31 pre-defined, 24 customisable)
- Choice of 6 languages – from a wide range downloadable
- Balance, mouse & printer connections
- No loss of nitrogen: distillate temperature stays below threshold
- Accurate dosing of reagents with high precision pumps
Versatile Data Handling
- Multiple data interfaces: Ethernet, USB and RS 232C
- On-board archiving of data including from balance
- Data exporting to pen drive or PC in .xls format
- Data manipulation software can be user preferred
Outstanding Reliability
- Maintenance-free, resistant, patented steam generator
- Patented titanium condenser for unmatched performance
- Durable technopolymer splash head
- Chemically-resistant technopolymer housing
Operator Safety
- Lever operation simplifies tube insertion / removal (all sizes)
- Protection screen for distillation chamber
- Drip tray collects splashes
- Zero pressure steam generator
Ecology & Standards
- Performs to AOAC, EPA, DIN and ISO standards
- Incorporates TEMS™ technology
- Automated water supply control reduces consumption
|
|
GENERAL FEATURES
| Structure: | Corrosion-resistant technopolymer |
| Display: | 6" colour touch screen |
| Time related to start for Devarda alloy analysis: | 0 – 99 min |
| Protocol library: | 55 methods: 31 pre-installed + 24 customisable |
| Reproducibility (RSD): | ≤ 1 % |
| Recovery: | ≥ 99.5 % at nitrogen levels between 1 and 200 mg N |
| Detection Limit: | ≥ 0.1 mg N |
| Power: | 2200 W |
| Weight: | 31 kg / 68.3 lb |
| Dimensions (WxHxD): | 385x780x416 mm (15.2x30.7x16.4 in) |
|
|
PERFORMANCE
| Distillation time: | From 4 minutes (including titration) |
| Sodium hydroxide addition: | Automatic |
| Water addition: | Automatic |
| Boric acid addition: | Automatic |
| Sodium hydroxide volume: | 0 - 150 ml |
| Water volume: | 0 - 200 ml |
| Boric acid volume: | 0 - 100 ml |
| Distillation and titration residues removal: | Automatic |
| Steam flow regulation: | From 10 to 100 % |
| Tap water consumption: | From 0,5 l/min at 15 °C – from 1 l/min at 30 °C |
| Connections: | Ethernet, 2 x USB and RS232 for PC, printer, mouse, pen drive, balance |
| On-board archive for data storage | |
|
